HOROTEC® Hand Fitting Tool on Rotating Base

MSA05.020 HOROTEC® Hand Fitting Tool on Rotating Base

Fit watch hands with the precision and confidence of a professional. The HOROTEC® MSA05.020 features a rotating base for easy repositioning and 8 PEEK tips covering a wide range of cannon pinion and hand tube diameters — from a flat 2.00 mm tip to a 2.10 mm inner diameter for larger hands. PEEK material ensures no marking of hands or dials during fitting.

What's Included

• 8 × PEEK tips (see sizes below)
• 1 × Handle (05.031-M)
• 1 × Rotating base (05.031-S)
• 1 × Protective cap (05.031-E)

PEEK Tip Sizes

• 05.031-0 — Flat tip, Ø ext. 2.00 mm
• 05.031-0.30 — Ø int. 0.30, Ø ext. 2.50 mm
• 05.031-0.80 — Ø int. 0.80, Ø ext. 2.60 mm
• 05.031-0.95 — Ø int. 0.95, Ø ext. 2.80 mm
• 05.031-1.10 — Ø int. 1.10, Ø ext. 2.90 mm
• 05.031-1.35 — Ø int. 1.35, Ø ext. 3.00 mm
• 05.031-1.50 — Ø int. 1.50, Ø ext. 3.20 mm
• 05.031-2.10 — Ø int. 2.10, Ø ext. 3.50 mm

Why PEEK?

PEEK (polyetheretherketone) is a high-performance polymer used in aerospace applications. It offers excellent solvent resistance, dimensional stability, and — critically for watchmaking — it won't mark or scratch hands or dials during fitting.
